8. The battery intelligent protection system can effectively prevent overcharge, overdischarge, overcurrent, short circuit and other problems.
Electrical Specification:
1. DC input voltage and current limits
Allowable minimum: DC 15V/3A
Allowable maximum: DC 25V/3A
2. AC output voltage range: 190V-230V
3. AC output frequency range
220V output: 47Hz-53Hz
110V output: 57Hz-63Hz
4. AC output power
Continuous Working Power: 300W-350W
5. DC Output voltage range
Function of Button
1. Press and hold the DC key for 3S to open the DC output, while the screen displays battery percentage and DC OUT; Double-click the DC button again to turn on the light, click the DC button again will switch the light. mode, double-click the DC button again will turn off the light.
2. Press and hold the AC key for 3S to open the AC output, and the screen displays the battery percentage and AC OUT. Hold down the AC button for 3S to turn off AC output.
3. The AC/DC output is turned on and the screen displays the battery percentage, AC OUT, DC OUT.
| Cell voltage | Cell capacity | Combination mode | Battery pack voltage | Battery pack voltage capacity | Power | ||||||
| 3.7V | >2560mAh | 3S17P | 11.1V | >44.2Ah | >490Wh | ||||||
Why choose Joypo?
* ISO 9001 & 14001 management certified factory
* Multiple production lines and multiple production workers
* Strict quality control process before, during and after production, 100% quality test before leaving factory
* Production integration
